Table 14.2 – %SR Registers
Register
Name
Description
Min Val
Max Val
%SR30
NET_BAUD
Network Baud Rate
(0=125KB; 1=250KB; 2=500KB; 3=1MB)
0
3
CsCAN Mode
0
3
DeviceNet Mode
0
2
CANOpen Mode
0
3
J1939
1
1
%SR31
NET_MODE
Network Mode (0=network not required;
1=network required; 2=network optimized;
3=network required and optimized)
0
3
%SR32
LCD_CONT
LCD Display Contrast setting
0
255
(Cscape
says 40)
%SR33
FKEY_MODE
Function Key Mode (0=Momentary; 1=Toggle)
0
1
%SR34
SERIAL_PROT
RS232 Serial Protocol Mode
(0=Firmware Update (RISM); 1=CsCAN;
2=Generic (Ladder- Controlled); 3=Modbus
RTU; 4=Modbus ASCII)
0
4
%SR35-36
SERIAL_NUM
This Station’s 32-bit Serial Number Low &
High
0
2
32
-1
%SR37
MODEL_NUM
This Station’s Binary Model Number
0
65535
%SR38
ENG_REV
Firmware Rev Number ( / 100)
0000
9999
%SR39
CPLD_REV
BIOS Rev Number ( / 100)
000
255
%SR40
FPGA_REV
FPGA Image Rev Number ( / 10)
000
255
%SR41
LCD_COLS
Vertical Pixel Count
%SR42
LCD_ROWS
Horizontal Pixel Count
%SR43
KEY_TYPE
Keypad Type
%SR44
RTC_SEC
Real-Time-Clock Second
0
59
%SR45
RTC_MIN
Real-Time-Clock Minute
0
59
%SR46
RTC_HOUR
Real-Time-Clock Hour
0
23
%SR47
RTC_DATE
Real-Time-Clock Date
1
31
%SR48
RTC_MON
Real-Time-Clock Month
1
12
%SR49
RTC_YEAR
Real-Time-Clock Year
1996
2095
%SR50
RTC_DAY
Real-Time-Clock Day (1=Sunday)
1
7
%SR51
NET_CNT
Network Error Count
0
65535
%SR52
WDOG_CNT
Watchdog-Tripped Error Count
0
65535
%SR53-55
Reserved
%SR56
LAST_KEY
Key Code of Last Key Press or Release
0
255
%SR57
BAK_LITE
LCD Backlight Dimmer Register
0 = 0% On; 25=25% On; 100-255 = 100% On
0
255
%SR59
Build Number
-
-
%SR60
Build Option
Build Test = 0, Build Beta = 1, Build Product = 2
%SR61
NUM_IDS
This Station’s Number of Network IDs
1
253
%SR62
Port Test Register
Serial Port Test = 0
Serial Port Loopback Test Init = 769
%SR63-135
Reserved
%SR136 -137
Communication Time Out
%SR138-163
Reserved
%SR164.3
AUTO_RESTRD
Read bit indicating Auto Restore of Register
Data has been performed (Fail Safe)
%SR164.4
BCKUP_TAKN
Read bit indicating Backup of Register Data
has been performed (Fail Safe)
