Table 14.2 – %SR Registers
Register
Name
Description
Min Val
Max Val
%SR164.5
EN_AUTO_RN
Enable AUTORUN (Fail Safe)
%SR164.6
EN_AUTO_LD
Enable AUTOLOAD (Fail Safe)
%SR164.7
STRT_BCKUP
Backup trigger bit
%SR164.8
CLR_BACKUP
Clear Backup trigger bit
%SR164.9
MAKE_CLONE
MAKE_CLONE trigger bit
%SR164.10
LOAD_CLONE
LOAD_CLONE trigger bit
%SR164.11
MK_CLN_FL
Status indicating Make Clone Fail (This bit
goes high when Make / Create clone fails)
%SR164.12
LD_CLN_FL
Status indicating Load Clone Fail (This bit
goes high when Load clone fails)
%SR165-166
Reserved
%SR167
Screen Update Time
2
50
%SR168-173
Reserved
%SR174
Removable Media
Removable Media Protect
%SR175
Removable Media
Current Removable Media interface status
0
6
%SR176-177
Removable Media
Indicates free space on the Removable Media
card in K bytes.
0
2
31
%SR178-179
Removable Media
Indicates the total card capacity in K bytes.
0
2
31
%SR180
Reserved
%SR181
ALM_UNACK
Unacknowledged Alarm (high bit indicates
what group #)
%SR182
ALM_ACT
Active Alarm (high bit indicates what group #)
%SR183
SYS_BEEP
System Beep Enable (0=disabled; 1=enabled)
0
1
%SR184
USER_BEEP
Software configurable (0=OFF; 1=ON)
0
1
%SR185
SCR_SAVER
Screen Saver Enabled (0=disabled; 1=enabled)
0
1
%SR186
SCR_SA_TM
Screen Saver Time in minutes (delay)
5
1200
%SR187
NET_USE
Average Net Usage of all units on the CAN
network
0
1000
%SR188
NET_MIN
Minimum Net Usage of all units on the CAN
network
0
1000
%SR189
NET_MAX
Maximum Net Usage of all units on the CAN
network
0
1000
%SR190
NT_TX_AVG
Average Net Usage of this unit
0
1000
%SR191
NT_TX_MIN
Minimum Net Usage of this unit
0
1000
%SR192
NT_TX_MAX
Maximum Net Usage of this unit
0
1000
For additional information on system bits and registers, refer to the Help file in Cscape.
