Hotone Ampero User Manual

DESIG N IN SP IRATION
Using the Screen
Touch operation
Changing patches and editing settings can all be done with the touchscreen.
Quick Access Knobs
The quick access knobs allow you to change the values of the three parameters directly above on the touch screen.
Main Knob
Turning the main knob lets you select the object you want to control. That object will light up when selected, then press the knob to confirm the selection.
• If the object selected is a button, it will respond as if you’d touched the button on the touchscreen.
• If the object selected is a parameter, you can use the main knob to adjust the parameter value. Pressing the main knob again will take you back to selection mode.
Reminder: The details of Ampero’s use and programming may slightly vary under certain operational circumstances. Please read this manual carefully to get all the
necessary information.
8

Hotone Ampero Specifications

Audio Processing

digital audio signal processing bit depth	24-bit
digital audio signal processing sample rate	44.1kHz
signal-to-noise ratio	120dB

Effects and Patches

effects	242
effects modules	Total of 9 simultaneous
patches	198 (99 user patches, 99 factory patches)

Looper and Drum Machine

looper time mono	100 seconds
looper time stereo	50 seconds
internal drum machine rhythm patterns	100

Inputs

instrument jack	One 1/4” Tip Sleeve (TS)
auxiliary input jack	One 1/8” Stereo
expression pedal input jack	One 1/4” Tip Ring Sleeve (TRS)

Outputs

unbalanced stereo output jacks	Two 1/4” Tip Sleeve (TS)
balanced stereo output jacks	Two XLR
headphones output jack	One 1/8” Stereo

Resistance

instrument input resistance	E.GT: 1MΩ; A.GT: 4.7MΩ; LINE: 10kΩ
aux in resistance	10kΩ
output resistance unbalanced	3.2kΩ

Display and Connectivity

screen size	4”
display resolution	800 x 480
usb port	USB 2.0 Type-B

Power

power requirements	18V DC Center Negative
current consumption	500mA Max
weight	1408g

Dimensions

length	320mm
width	147mm
height	46mm
