Hotone Ampero User Manual

DESIG N IN SP IRATION
Definitions
Module
Ampero supports the simultaneous use of up to 9 effects. Each is called an “effects module”, or simply “module”. There are several effects available in each module.
Parameter
Variables that determine the application of an effect are called “parameters”. If we imagine each module as a separate effect pedal, then each parameter would be a
knob on that pedal.
Patch
The ON/OFF status of each module and the parameter settings are stored in units called “patches”. These are your “tones”. Use patches to recall, edit, and save your
favorite tones.
Bank
A set of 3 patches is called a “bank”. Ampero has a total of 66 banks, including 33 editable player (user) banks and 33 factory banks (F01-F33), which can be adjusted by
not saved.
3

Hotone Ampero Specifications

Audio Processing

digital audio signal processing bit depth	24-bit
digital audio signal processing sample rate	44.1kHz
signal-to-noise ratio	120dB

Effects and Patches

effects	242
effects modules	Total of 9 simultaneous
patches	198 (99 user patches, 99 factory patches)

Looper and Drum Machine

looper time mono	100 seconds
looper time stereo	50 seconds
internal drum machine rhythm patterns	100

Inputs

instrument jack	One 1/4” Tip Sleeve (TS)
auxiliary input jack	One 1/8” Stereo
expression pedal input jack	One 1/4” Tip Ring Sleeve (TRS)

Outputs

unbalanced stereo output jacks	Two 1/4” Tip Sleeve (TS)
balanced stereo output jacks	Two XLR
headphones output jack	One 1/8” Stereo

Resistance

instrument input resistance	E.GT: 1MΩ; A.GT: 4.7MΩ; LINE: 10kΩ
aux in resistance	10kΩ
output resistance unbalanced	3.2kΩ

Display and Connectivity

screen size	4”
display resolution	800 x 480
usb port	USB 2.0 Type-B

Power

power requirements	18V DC Center Negative
current consumption	500mA Max
weight	1408g

Dimensions

length	320mm
width	147mm
height	46mm
