HP 1910 - V1910-16 G Panel Views; V1910-24 G Panel Views

2
V1910-16G panel views
Figure 1 Front panel
(1) 10/100/1000Base-T auto-sensing Ethernet port (2) 1000Base-X SFP port
(3) Console port (4) Port LED
(5) Power LED (Power)
Figure 2 Rear panel
(1)
A
C-input power receptacle (2) Groundin
g
screw
V1910-24G panel views
Figure 3 Front panel
(1) 10/100/1000Base-T auto-sensin
g
Ethernet port
(2) 1000Base-X SFP port
(3) Console port (4) Port LED
(5) Power LED (Power)
Figure 4 Rear panel
(1)
A
C-input power receptacle (2) Groundin
g
screw
