V1910-48G panel views
Figure 5 Front panel
(1) 10/100/1000Base-T auto-sensing Ethernet port
(2) 10/100/1000Base-T Ethernet port LED
(3) Console port (4) Power LED (Power)
(5) 1000Base-X SFP port (6) 1000Base-X SFP port LED
Figure 6 Rear panel
(1) AC-input power receptacle (2) Grounding screw
V1910-24G-PoE (170W) panel views
Figure 7 Front panel
(1) 10/100/1000Base-T auto-sensing Ethernet port (2) Port LED mode switching button
(3) Port LED (4) Power LED (Power)
(5) Port mode LED
(6) Console port
(7) 1000Base-X SFP port
