HP 1910 - 1910-8 G-Poe+ (65 W) Panel Views

5
(5) Power LED (Power)
Figure 12 Rear panel
(1) AC-input power receptacle (2) Grounding screw
1910-8G-PoE+ (65W) panel views
Figure 13 Front panel
(1) 10/100/1000Base-T auto-sensin
g
Ethernet port
(2) Port LED mode switchin
g
button
(3) Port LED (4) Power LED (Power)
(5) Port mode LED
(6) Console port
(7) 1000Base-X SFP port
Figure 14 Rear panel
(1)
A
C-input power receptacle (2) Groundin
g
screw
45
1 2 3
67
