Solid-state drive
IMPORTANT: The solid-state drive installs into the same M.2 connector as the Optane memory module.
Both the solid-state drive and the Optane memory module cannot be installed at the same time.
1. Prepare the computer for disassembly (see Preparation for disassembly on page 14).
2. Remove the stand assembly (see Stand assembly on page 15).
3. Remove the display (see Display on page 16).
4. Remove the two Phillips screws that secure the M.2 module bracket to the system board (1).
5. Remove the bracket from the computer (2).
6. Remove the Phillips screw (1), and then pull the drive away from the connector (2).
Reverse this procedure to install the solid-state drive.
24 Chapter 4 Removal and replacement procedures
