HP 200 G3 User Manual

Discrete graphics card
1. Prepare the computer for disassembly (see Preparation for disassembly on page 14).
2. Remove the stand assembly (see Stand assembly on page 15).
3. Remove the display (see Display on page 16).
4. Remove the fan (see Fan on page 27).
5. Remove the heat sink (see Heat sink on page 28).
6. Remove the four Phillips screws that secure the card to the system board (1).
7. Rotate the front of the card upward, and then pull the card away from the connector and out of the
computer (2).
Reverse this procedure to install the discrete graphics card.
Discrete graphics card 29

HP 200 G3 Specifications

General

Memory Type	DDR4
Processor	Intel Core i3/i5/i7
Storage	500 GB HDD; 128 GB SSD
Operating System	Windows 10 Pro
Ports	USB 2.0, HDMI, VGA, Ethernet, Audio
