WLAN module
The WLAN module is located next to the memory modules.
For a list of available WLAN modules, see Computer major components on page 4.
1. Prepare the computer for disassembly (Preparation for disassembly on page 16).
2. Remove the display (see Display on page 18).
3. Disconnect the antenna cables from the module (1).
4. Remove the Phillips screw (2), and then pull the module out of the socket (3).
To install the WLAN module, reverse the removal procedures.
WLAN module 27
