Speakers
1. Prepare the computer for disassembly (Preparation for disassembly on page 16).
2. Remove the display (see Display on page 18).
3. Remove the power button/card reader board (see Power button/card reader board on page 30).
4. Disconnect the two speaker cables from the system board (1).
5. Pull the speakers o the installation posts and out of the computer (2).
TIP: When installing the speakers, make sure the rubber gasket is in place in the speakers and over the
installation posts (3).
To install the speakers, reverse the removal procedures.
Speakers 31
