HP 200 G4 22

Heat sink
1. Prepare the computer for disassembly (Preparation for disassembly on page 16).
2. Remove the display (see Display on page 18).
3. Remove the fan (see Fan on page 26).
4. Loosen the three captive Phillips screws (1) that secure the heat sink to the computer.
5. Remove the heat sink from the computer (2).
Heat sink 33
