B-16
Table B-22.
A2994A PowerTrust UPS Specifications.
Description Specification
Electrical Specifications:
AC Line Input:
Rated Voltage 100-120/200-240 VAC 50/60 Hz (Auto-ranging)
Rated Current 14 to 12 Amps and 7 to 6 Amps
(20 Amp max branch circuit overcurrent protection)
AC Output:
Output VAC
(On Line Power)
Approximately equal to AC line input power
Output VAC
(On Battery)
115 VAC or 230 VAC at 50/60Hz
(+
10% with full load)
Range VA/Watts 1300/1300 @ 0.5 to 1.0 power factor
Transfer Time AC Failure - <
10 msec to switch to battery power
AC Restored -5 Second delay returning to input AC phase lock
Phasing Phase locked to within 5º of input utility AC
Safety Agency Approvals Agency approvals: UL, CSA, and TUV
Battery:
Type Maintenance-free, sealed, computer grade, lead-acid type
Nominal open
circuit voltage 60 VDC
Reserve time Approximately 15 minutes (at full load)
Battery Recharge
Time
<
14 Hours with output switch in the ON position
(after full discharge)
<
24 Hours with output switch in the OFF position
(after full load discharge)
Optimum Battery
Lifetime 3.5 to 5 years
