52
Figure 13 Network diagram
Internet
Switch
SSH user
RADIUS server
10.1.1.1/24
VLAN-int2
192.168.1.70/24
-int3
10.1.1.2/24
VLAN
Configuration procedure
1. Configure the RADIUS server (iMC PLAT 5.0)
NOTE:
This example assumes that the RADIUS server runs iMC PLAT 5.0 (E0101) and iMC UAM 5.0 (E0101).
# Add an access device.
Log in to the iMC management platform, click the Service tab, and select User Access Manager > Access
Device from the navigation tree to enter the Access Device page. Then, click Add to enter the Add Access
Device window and perform the following configurations as shown in Figure 14.
• S
e
t the shared key for secure authentication and accounting communication to expert
• Specify the ports for authentication and accounting as 1812 and 1813 respectively
• Select Device Management Service as the service type
• Select HP(A-Series) as the access device type
• Select the switch from the device list or manually add the switch with the IP address of 10.1.1.2
• Click OK to finish the operation
NOTE:
The IP address of the access device specified here must be the same as the source IP address of the RADIUS
packets sent from the switch, which is the IP address of the outbound interface by default, or otherwise the
IP address specified with the nas-ip or radius nas-ip command on the switch.
