9
5120-24G SI panel views
Figure 17 Front panel
(1) 10/100/1000Base-T auto-sensing Ethernet port (2) 1000Base-X SFP port
(3) Console port (4) Port LED
(5) Power LED (Power)
Figure 18 Rear panel
(1) AC-input power receptacle (2) Grounding screw
5120-48G SI panel views
Figure 19 Front panel
(1) 10/100/1000Base-T auto-sensing Ethernet port
(2) 10/100/1000Base-T Ethernet port LED
(3) Console port (4) Power LED (Power)
(5) 1000Base-X SFP port (6) 1000Base-X SFP port LED
Figure 20 Rear panel
(1) AC-input power receptacle (2) Grounding screw
