5120-24G-PoE+ SI panel views
Figure 27 Front panel
(1) 10/100/1000Base-T auto-sensing Ethernet port (2) Port LED mode switching button
(3) RPS status LED (RPS) (4) Port LED
(5) Power LED (Power) (6) Port mode LED
(7) Console port (8) 1000Base-X SFP port
Figure 28 Rear panel
(1) DC receptacle (2) Screw hole of the plug
(3) AC-input power receptacle (4) Grounding screw
