HP 5120 EI Series Installation Guide

72
10-GE XFP transceiver modules
Product code
Module
description
Central
wavelength
(nm)
Fiber
diameter
(μm)
Multimode
fiber modal
bandwidth
(MHz × km)
Max transmission
distance
2000 300 m (984.25 ft)
500 82 m(269.03 ft)
50/125
400 66 m(216.54 ft)
220 33 m (108.27 ft)
JD117B
HP X130 10G
XFP LC SR
Transceiver
850
62.5/125
160 26 m (85.3 ft)
JD108B
HP X130 10G
XFP LC LR
1310nm
Transceiver
1310 9/125 N/A 10 km (6.21 miles)
JD121A
HP X135 10G
XFP LC ER
Transceiver
1550 9/125 N/A 40 km (24.86 miles)
JD107A
HP X130 10G
XFP LC ZR
1550nm
Transceiver
1550 9/125 N/A 80 km (49.71 miles)
CX4 cables
Product code Cable description Connector type Cable length
JD363B
HP X230 Local Connect 50cm
CX4 Cable
4X Infiniband 0.5 m (19.69 in)
JD364B
HP X230 Local Connect 100cm
CX4 Cable
4X Infiniband 1 m (39.37 in)
JD365A HP X230 CX4 to CX4 3m Cable 4X Infiniband 3 m (118.11 in)
Figure 87 CX4 cable
(1) Pull latch (2) Connector
