HP 5120 EI Series

76
Combo interface (only available on the 5120 EI switches)
On a 5120 EI switch, the last four 10/100/1000Base-T Ethernet ports and the four SFP ports are
copper/fiber combo ports in pairs, as shown in Table 17.
They form four combo interfaces. When one
port in a pair is activated, the other port automatically shuts down. For more information about combo
interfaces, see HP 5120 EI Switch Series Configuration Guides.
Table 17 Copper/fiber combo ports in pairs
Chassis SFP port 10/100/1000Base-T Ethernet port
GigabitEthernet 1/0/25 GigabitEthernet 1/0/22
GigabitEthernet 1/0/26 GigabitEthernet 1/0/24
GigabitEthernet 1/0/27 GigabitEthernet 1/0/21
5120-24G EI (2 slots)
5120-24G EI TAA (2 slots)
5120-24G-PoE+ EI (2 slots)
5120-24G-PoE+ EI TAA (2 slots)
5120-24G EI
GigabitEthernet 1/0/28 GigabitEthernet 1/0/23
GigabitEthernet 1/0/49 GigabitEthernet 1/0/46
GigabitEthernet 1/0/50 GigabitEthernet 1/0/48
GigabitEthernet 1/0/51 GigabitEthernet 1/0/45
5120-48G EI (2 slots)
5120-48G EI TAA (2 slots)
5120-48G-PoE+ EI (2 slots)
5120-48G-PoE+ EI TAA (2 slots)
5120-48G EI
GigabitEthernet 1/0/52 GigabitEthernet 1/0/47
LEDs (for the 5120 EI switches)
Table 18 LEDs at a glance
LED Availability
System status LED Entire series
RPS status LED Entire series
Port mode LED Entire series
Seven-segment LED Entire series
10/100/1000Base-T Ethernet port LED Entire series
SFP port LED Entire series
Interface card status LED Entire series (except the 5120-24G EI and 5120-48G EI)
System status LED
The system status LED shows the operating status of the switch.
Table 19 System status LED description
LED mark Status Description
Steady green The switch is operating properly. PWR
Flashing green (1 Hz)
The switch is performing power-on self
test (POST).
