HP 5120 EI Series Installation Guide

70
GE SFP transceiver modules
Product
code
Module description
Central
wavelength
(nm)
Cable/fiber
diameter
(μm)
Multimode
fiber modal
bandwidth
(MHz × km)
Max
transmission
distance
500
550 m
(1804.46 ft)
50/125
400
500 m
(1640.42 ft)
200
275 m
(902.23 ft)
JD118B
HP X120 1G SFP LC SX
Transceiver
850
62.5/125
160
220 m
(721.78 ft)
9/125 N/A
10 km (6.21
miles)
50/125 500, 400
550 m
(1804.46 ft)
JD119B
HP X120 1G SFP LC LX
Transceiver
1310
62.5/125 500
550 m
(1804.46 ft)
JD061A
HP X125 1G SFP LC LH40
1310nm Transceiver
1310 9/125 N/A
40 km (24.86
miles)
JD062A
HP X120 1G SFP LC LH40
1550nm Transceiver
1550 9/125 N/A
40 km (24.86
miles)
JD063B
HP X125 1G SFP LC LH70
Transceiver
1550 9/125 N/A
70 km (43.50
miles)
JD103A
HP X120 1G SFP LC
LH100 Transceiver
1550 9/125 N/A
100 km (62.14
miles)
JD098B
HP X120 1G SFP LC BX
10-U Transceiver
TX: 1310nm
RX: 1490nm
9/125 N/A
10 km (6.21
miles)
JD099B
HP X120 1G SFP LC BX
10-D Transceiver
TX: 1490nm
RX: 1310nm
9/125 N/A
10 km (6.21
miles)
JD089B
HP X120 1G SFP RJ45 T
Transceiver
N/A
Category-5
twisted pair
N/A
100 m
(328.08 ft)
IMPORTANT:
You must use the transceiver modules coded JD098B and JD099B in pairs.
10-GE SFP+ transceiver modules
Product code
Module
description
Central
wavelength
(nm)
Fiber
diameter
(μm)
Multimode fiber
modal bandwidth
(MHz × km)
Max
transmission
distance
JD092B
HP X130 10G
SFP+ LC SR
850 50/125
2000
300 m (984.25
ft)
