HP 54645A/D Performance Test Record
Serial No. ______________________________________ Test by____________________________
Test Interval ____________________________________ Work Order No._____________________
Recommended Next Testing _______________________ Temperature _______________________
Threshold Accuracy
±
(100 mV + 3% of threshold setting)
Ch D0-D7 Ch D8-D15
Test Specification Limits
+5 V – 250 mV +4.750 V _____________ _____________
+5 V + 250 mV +5.250 V _____________ _____________
–5 V – 250 mV –5.250 V _____________ _____________
–5 V + 250 mV –4.750 V _____________ _____________
0 V – 100 mV –100 mV _____________ _____________
0 V + 100 mV +100 mV _____________ _____________
Calibrator Output Nominal Test Limits Results
dc 0
µ
V –500
µ
V to +500
µ
V _____________
5 V 4.990 V to 5.010 V _____________
Voltage measurement accuracy
Range Power Supply Setting Test Limits Channel 1 Channel 2
5 V/Div 35 V 34.24 V to 35.76 V _____________ _____________
2 V/Div 14 V 13.696 V to 14.304 V _____________ _____________
1 V/Div 7 V 6.848 V to 7.152 V _____________ _____________
500 mV/Div 3.5 V 3.424 V to 3.576 V _____________ _____________
200 mV/Div 1.4 V 1.3696 V to 1.4304 V _____________ _____________
100 mV/Div 700 mV 684.8 mV to 715.2 mV _____________ _____________
50 mV/Div 350 mV 342.4 mV to 357.6 mV _____________ _____________
20 mV/Div 140 mV 136.96 mV to 143.04 mV _____________ _____________
10 mV/Div 70 mV 68.48 mV to 71.52 mV _____________ _____________
5 mV/Div 35 mV 34.24 mV to 35.76 mV _____________ _____________
2 mV/Div 14 mV 13.696 mV to 14.304 mV _____________ _____________
1 mV/Div 7 mV 6.696 mV to 7.304 mV _____________ _____________
Bandwidth Test Limits Channel 1 Channel 2
≤ ±
3 dB at 100 MHz _____________ _____________
≤ ±
3 dB at 75 MHz _____________ _____________
Horizontal
∆
t and 1/
∆
t accuracy
Generator Setting Test Limits Results
Frequency 10 kHz 9.96 kHz to 10.04 kHz _____________
Period 100
µ
s 99.59
µ
s to 100.41
µ
s _____________
Frequency 1 MHz 995.9 kHz to 1.0042 MHz _____________
Period 1
µ
s 995.9 ns to 1.0041
µ
s _____________
Frequency 100 MHz 98.61 MHz to 101.43 MHz _____________
Period 10 ns 9.86 ns to 10.14 ns _____________
Trigger sensitivity Test Limits Channel 1 Channel 2
Internal trigger 25 MHz at 0.35 divisions _____________ _____________
100 MHz at 1 division _____________ _____________
External
External trigger 100 MHz at 100 mV
p-p
_____________
25 MHz at 50 mV
p-p
_____________
Option 005 Voltage measurement accuracy Test Limits Channel 1 Channel 2
Amplitude peak-to-peak
≥
63.6 mV
p-p
_____________ _____________
7-28
