HP 5500 HI Series Installation Guide

48
Item
5500-24G-4SFP HI (2
slots)
5500-48G-4SFP HI (2
slots)
5500-24G-SFP HI (2
slots)/5500-24G-SFP HI
TAA (2 slots)
Melting current of power
supply fuse
• AC-input: 3.15A/250V
• DC-input: 8A/250V
Operating temperature
0°C to 50°C (32°F to 122°F) or 0°C to 45°C (32°F to 113°F) when the
XFP-LH40-SM1550-F1 or XFP-LH80-SM1550 is used
Relative humidity 5% to 95%, noncondensing
Fire resistance
compliance
UL60950-1, EN60950-1, IEC60950-1, GB4943
Table 10 HP 5500 HI switches technical specifications (II)
Item
5500-24G-PoE+-4SFP HI (2 slots)/
5500-24G-PoE+-4SFP HI TAA (2
slots)
5500-48G-PoE+-4SFP HI (2 slots)/
5500-48G-PoE+-4SFP HI TAA (2
slots)
Dimensions (H × W × D)
43.6 × 440 × 460 mm
(1.72 × 17.32 × 18.11 in)
43.6 × 440 × 460 mm
(1.72 × 17.32 × 18.11 in)
Weight < 10 kg (22.05 lb) < 10.5 kg (23.15 lb)
Management ports 1 console port, 1 management Ethernet port, both on the front panel
Fixed network ports (on
the front panel)
• 24 × 10/100/1000Base-T
auto-sensing Ethernet ports
• 4 × 100/1000Base-X SFP ports
• 2 × 1/10 Gbps SFP+ ports
• 48 ×10/100/1000Base-T
auto-sensing Ethernet ports
• 4 × 100/1000Base-X SFP ports
• 2 x 1/10 Gbps SFP+ ports
Expansion interface
card slots
2 (SLOT1 and SLOT2), on the rear panel
2 (SLOT1 and SLOT2), on the rear panel
Power supply slots 2, on the rear panel 2, on the rear panel
Input voltage
• PSR720-56A (JG544A) AC-input
{ Rated voltage range: 100 VAC to 240 VAC @ 50 Hz or 60 Hz
{ Max voltage range: 90 VAC to 264 VAC @ 47 Hz to 63 Hz
• PSR1110-56A (JG545A) AC-input
{ Rated voltage range: 115 VAC to 240 VAC @ 50 Hz or 60 Hz
{ Max voltage range: 102.5 VAC to 264 VAC @ 47 Hz to 63 Hz
Maximum PoE power
consumption on a single
port
30 W 30 W
Total PoE power
consumption
Depending on configured power
supplies:
• One PSR720-56A: 450 W
• Two PSR720-56A: 720 W
• O n e P S R 111 0 - 5 6 A : 7 2 0 W
• One PSR720-56A and one
P S R 111 0 - 5 6 A : 7 2 0 W
• Two PSR1110-56A: 720 W
Depending on configured power
supplies:
• One PSR720-56A: 450 W
• Two PSR720-56A: 1100 W
• O n e P S R 111 0 - 5 6 A : 8 0 0 W
• One PSR720-56A and one
P S R 111 0 - 5 6 A : 14 4 0 W
• Two PSR1110-56A: 1440 W
