56
Product
code
Module description
Central
wavelength
(nm)
Fiber
diameter
(μm)
Multimode
fiber modal
bandwidth
(MHz
×
km)
Max transmission
distance
JD107A
HP X130 10G XFP LC
ZR 1550nm
Transceiver
1550 9/125 N/A 80 km (49.71 miles)
CX4 cables
Product code CX4 cable model Connector Max transmission distance
JD363B
HP X230 Local Connect 50cm
CX4 Cable
4X Infiniband 0.5 m (1.64 ft)
JD364B
HP X230 Local Connect 100cm
CX4 Cable
4X Infiniband 1 m (3.28 ft)
JD365A HP X230 CX4 to CX4 3m Cable 4X Infiniband 3 m (9.84 ft)
Figure 58 CX4 cable assembly
(1) Pull latch (2) Connector
