HP 5500 HI Series Installation Guide

54
Product
code
Module description
Central
wavelength
(nm)
Cable/fiber
diameter
(μm)
Multimode
fiber modal
bandwidth
(MHz × km)
Max
transmission
distance
JD063B
HP X125 1G SFP LC LH70
Transceiver
1550 9/125 N/A
70 km (43.50
miles)
JD103A
HP X120 1G SFP LC
LH100 Transceiver
1550 9/125 N/A
100 km (62.14
miles)
JD098B
HP X120 1G SFP LC BX
10-U Transceiver
TX: 1310
RX: 1490
9/125 N/A
10 km (6.21
miles)
JD099B
HP X120 1G SFP LC BX
10-D Transceiver
TX: 1490
RX: 1310
9/125 N/A
10 km (6.21
miles)
JD089B
HP X120 1G SFP RJ45 T
Transceiver
N/A
Category-5
twisted pair
N/A
100 m
(328.08 ft)
IMPORTANT:
You must use the transceiver modules coded JD098B and JD099B in pairs.
10 Gbps SFP+ transceiver modules/SFP+ cables
Product
code
Module description
Central
wavelength
(nm)
Fiber
diameter
(μm)
Multimode fiber
modal bandwidth
(MHz × km)
Max
transmission
distance
Transceiver modules
JD092B
HP X130 10G SFP+
LC SR Transceiver
850
50/125
2000
300 m (984.25
ft)
500 82 m (269.03 ft)
400 66 m (216.54 ft)
62.5/125
200 33 m (108.27 ft)
160 26 m (85.3 ft.)
JD093B
HP X130 10G SFP+
LC LRM Transceiver
1310
50/125
1500, 500
220 m (721.78
ft)
400
100 m (328.08
ft)
62.5/125 200, 160
220 m (721.78
ft)
JD094B
HP X130 10G SFP+
LC LR Transceiver
1310 9/125 N/A
10 km (6.21
miles)
JG234A
HP X130 10G SFP+
LC ER 40km
Transceiver
1550 9/125 N/A
40 km (24.86
miles)
