HP 5500 HI Series Installation Guide

55
Product
code
Module description
Central
wavelength
(nm)
Fiber
diameter
(μm)
Multimode fiber
modal bandwidth
(MHz × km)
Max
transmission
distance
SFP+ cables (short-haul)
JD095C
HP X240 10G SFP+
SFP+ 0.65m DA
Cable
N/A SFP+ cable N/A 0.65 m (2.13 ft)
JD096C
HP X240 10G SFP+
SFP+ 1.2m DA Cable
N/A SFP+ cable N/A 1.2 m (3.94 ft)
JD097C
HP X240 10G SFP+
SFP+ 3m DA Cable
N/A SFP+ cable N/A 3 m (9.84 ft)
JG081C
HP X240 10G SFP+
SFP+ 5m DA Cable
N/A SFP+ cable N/A 5 m (16.40 ft)
JC784C
HP X240 10G SFP+
SFP+ 7m Direct
Attach Copper Cable
N/A SFP+ cable N/A 7 m (22.97 ft)
Figure 57 SFP+ cable
(1) Pull latch (2) Connector
10 Gbps XFP transceiver modules
Product
code
Module description
Central
wavelength
(nm)
Fiber
diameter
(μm)
Multimode
fiber modal
bandwidth
(MHz
× km)
Max transmission
distance
JD117B
HP X130 10G XFP LC
SR Transceiver
850
50/125
2000 300 m (984.25 ft)
500 82 m(269.03 ft)
400 66 m(216.54 ft)
62.5/125
220 33 m (108.27 ft)
160 26 m (85.3 ft)
JD108B
HP X130 10G XFP LC
LR 1310nm
Transceiver
1310 9/125 N/A 10 km (6.21 miles)
JD121A
HP X135 10G XFP LC
ER Transceiver
1550 9/125 N/A 40 km (24.86 miles)
1
2
