HP 5800 Series Configuration Guide

39
Ste
p
Command Remarks
5. Configure the command level
for login users on the current
user interfaces.
user privilege level level
Required.
By default, the default command level is 0
for VTY user interfaces.
6. Configure common settings
for VTY user interfaces.
—
Optional.
See “Configuring common settings for VTY
user interfaces (optional).”
When you log in to the device through Telnet again:
• You enter the VTY user interface, as shown in Figure 11.
• If “A
ll user interfaces are used, please try later!” is displayed, it means the current login users exceed the
maximum number. Please try later.
Figure 11 Configuration page

HP 5800 Series Specifications

General

MAC Address Table Size	32, 000 entries
Uplink Ports	2 or 4 SFP+ 10GbE ports
Routing Protocol	BGP, IS-IS
Input Voltage	100-240 VAC
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 95% (noncondensing)
PoE	Optional
Power Supply	Redundant power supply (optional)
