3. Press in on the lockshaft on the flash card housing. The flash card
should eject until its left end is flush with the interface card.
4. Grasping the exposed end of the flash card, remove it from its
housing.
5. Position the new flash card to the left of the housing, with the HP
label facing up and the arrow on the label pointing toward the
housing.
6. Insert the right end of the flash card into the left end of the housing,
lifting it slightly to engage properly in the housing.
Figure 3-12. Ejecting Flash Card
Figure 3-13. Removing Flash Card
Troubleshooting
Replacing a Module
3-32
