Mount the router.
Before mounting the router, make sure the router’s power cord is
correct for your country’s ac power receptacle. Do not attach the power
cord yet.
Rack or Cabinet Mounting
Warning The rack or cabinet should be adequately secured to prevent it
from becoming unstable and/or falling over.
1. Remove the protective film from the top and front of the router.
2. Using a Phillips (cross-head) screwdriver, remove the top and
bottom screws from the front of one side of the router (see figure
1-1). (Save these screws in case you later want to remove the router
from the rack or cabinet and mount it on a table instead.)
Figure 1-1. Screw Removal
Installation
Mount the router.
1-5

HP 650 Specifications

General

RAM	Up to 8GB DDR3
Display	15.6-inch HD (1366x768)
Graphics	Intel HD Graphics
Operating System	Windows 7 / Windows 8
Battery	6-cell Li-ion
Optical Drive	DVD±RW
Wireless	802.11b/g/n
Processor	Intel Celeron, Pentium, or Core i3/i5/i7 (various models available)
