4. Pull the handle on the power supply, and remove it from its
compartment.
5. Insert the new power supply into the compartment, and push it all
the way back.
6. Insert and tighten the screw(s) you removed in step 3.
7. Reconnect the power cord that you disconnected in step 1.
8. Switch the power supply on by pressing the top of the switch
(marked with “
| ”).
9. Close and lock the router door.
Reset Clear
Console RS-232
Power supply screws
Power supply screw
Figure 3-15. Power Supply Screws
Troubleshooting
Replacing a Module
3-35
