6-46 Removal and Replacement
Figure 6-30. (page 2 of 2)
(C)C2858-79
(C)C2858-80
(C)C2858-81
Sled Springs
Stops
Sled Rubber Tubes
Through Sled
Springs: (middle
tubes between
springs, outer
tubes outside
of springs)
Bail Sensor
Drop Detect Sensor
Tubes Through
Slot In Bottom Of
Service Station
Housing
Sled
Wiper Cap
