1-6 Product Information
PERFORMANCE CHARACTERISTICS
Table 1-2 lists the performance characteristics of the plotters.
Table 1-2. Performance Characteristics
Accuracy
0.38 mm (0.015 in.) or 0.2% of the specified vector length, whichever is
greater at 23 C (73 F) at 50-60% RH, on HP film (monochrome mode only).
Throughput
D-sized loaded vertically: plain paper special paper special paper
monochrome monochrome color
Draft mode 1.8 min. 1.8 min. 3.4 min.
Final mode 3.2 min. 2.7 min. 4.3 min.
Enhanced mode 6.5 min. 6.5 min. 8.7 min.
Resolution
Draft Mode 300 dpi addressable
Final Mode 300 dpi addressable
Enhanced Mode 300 dpi addressable (color)
600 dpi addressable (monochrome)
Margins
Leading and Trailing 17 mm ( 2mm) (normal plot area),
10 mm (expanded plot area)
Sides 5 mm (normal or expanded plot area)
Media Dimensions
Sheet and Roll
Maximum Widths D (A1)-size 619 mm (24 in.)
E (A0)-size 917 mm (36 in.)
Roll
Maximum Media Length 150 feet (125 ft. for film)
SERIAL NUMBER INFORMATION
If the plotter serial number has a lower revision letter than the one shown on the title page,
information in the Product History chapter, Chapter 9, will adapt this manual to that plotter.
