8-19Troubleshooting
CONFIGURATION PLOT
The configuration plot aids in the analysis of plotter problems by providing:
$"!$$$!’ & "!& %! &$ % %’$
’ #’ "&&$ %!$ ’% && " !,, "$!% " -&!-" -
& "$!% !) "$!% ($& %&$& %%!’$-%"$%$!%%$%!$%’$
"!&&$ " -&!-" ’$+
&$% ! &$!%%$% %!’"$&
" "&& %& ’" !$&!
& "!&&$ %&&%&% ’ ! $( !$&!
& "!$& "!&&$ %&-’" !$&!
&--! ’$&! %
& &*&!% ! &! & &% %&!$ &
Draft Mode should not be used when performing the configuration plot as the patterns drawn
will be different than described above.
To run the configuration plot, perform the following steps:
1. Switch the power ON.
2. Load D-size or E-size media (either sheet or rollfeed).
3. Ensure that the plotter is in the Full (long) menu mode.
4. Ensure that the plotter is in the ªFinalº as opposed to the ªDraftº mode.
5. From the ªStatusº menu display, press the ENTER button.
6. Using the ARROW buttons, scroll to the ªUtilitiesº menu.
7. Press the ENTER button.
8. Using the ARROW buttons, scroll to the ªConfig Plotº menu.
9. Press the ENTER button.
