2-2 Site Planning and Requirements
ELECTRICAL SPECIFICATIONS
POWER REQUIREMENTS
HP C2858A and C2859A DesignJet 650C plotters have self-adjusting power supplies and do
not require voltage selector or switch settings prior to use. Table 2-1 lists the power require-
ments for the plotters.
Table 2-1. Power Requirements
Voltage Requirements
Frequency
Source
Voltage Current (max)
100 Vac 1.4 A
120 Vac 1.2 A
220 Vac 650 mA
240 Vac 600 mA
47-53 Hz and 57-63 Hz
Consumption 140 Watts maximum
LINE CORD SET
W A R N I N G
The configuration of the ac line cord set required for use with the plotters is determined by the
country of destination for the plotters. Refer to Chapter 3 for a listing of the available ac line
cord connectors.
