6-48 Removal and Replacement
Figure 6-31.
Overdrive Assembly Shaft
Overdrive Assembly Clutch
Clutch Retainer
Overdrive Cluster Gear
Shoulder Screw
Overdrive Support Mount
Screw
Overdrive Support Mount
Screw
Left Side
Right Side
(C)C2858-10
(C)C2858-14
(C)C2858-12
