HP 650C User Manual

6-52 Removal and Replacement
5. When correctly installed, the right side of the entry platen will be against the right
sideplate and the top of the platen should be against the top reference pins in the left
and right sideplates.
Figure 6-33.
Wedge Screw
Top Screw
Top Screw
Wedge Screw
Left Side
Right Side
Pinch Arm
Lift Lever Screw
Front Locating Pin
Rear Locating Pins
(Outside View)
(Outside View)
(C)C2858-31b
(C)C2858-30b
