7-5Adjustments/Calibrations
3. Press Enter at the ªStatusº display.
4. Use the arrow buttons to scroll to the ªUtilitiesº main menu. Press Enter. If not
already set to Full menu mode, scroll to Full and press Enter.
5. User accuracy: Scroll to the ªAccuracyº submenu. Press Enter.
Service accuracy: Simultaneously press the Enter and Up Arrow buttons.
6. User accuracy: Scroll to the ªRecalibrateº submenu. Press Enter.
Service accuracy: Scroll to the ªAccuracy Calibº submenu. Press Enter.
The ªCreate plot / Measure plotº message displays.
7. Press the Up Arrow button to select ªCreate plot.º
A ªCreating calibration plotº message displays while plotting.
8. Wait until the ªRemove media / Continueº message displays.
9. Press the Down Arrow button to ªContinue.º
The ªCreate plot / Measure plotº message displays.
10. Press the Down Arrow button to select ªMeasure plot.º
11. Rotate the plot so that the edge with arrows points to the leading edge, then reload
the plot with the arrow edge print side down.
(C) C2847-15a(UM)
12. The plotter will load the plot and then measure the alignment marks using the edge
sensor on the pen carriage.
13. Press the Down Arrow button to continue when the ªCalibrate done / Continueº
message is displayed and the plot is fed out. Accuracy calibration is complete.
A Calibration Plot may be saved and reused for future calibrations by selecting ªMeasure
plotº when calibration is necessary.
