8-22 Troubleshooting
Table 8-4. EEROM Map
Address
Definition
Location
0
0 EEROM Initialized A (Value 55) (Read by Servo Processor)
0 1 EEROM Initialized B (Value AA) (Read by Servo Processor)
0 2 EEROM Initialized C (Value 5B) (Read by Servo Processor)
0 3 Power-up Mode
0 4 FP General Byte
0 5 FP PostScript Byte
0 6 EEROM Pen C DT Offset
EEROM Baud Byte
EEROM Handshake Byte
EEROM Parity Byte
0 7 EEROM Pen Y DT Offset
0 8 EEROM Language Byte
EEROM Cutter Mode Byte
EEROM Print Mode Byte
EEROM Media Format Byte
EEROM Media Type Byte
0 9 EEROM Sheet Length
0 F MIO Initialized
1 0 MIO Storage Begin
1 1 ROM Location
1 2 DRAM Location
1 3 MIO Storage End
1 5 Swath RAM Location
1 7 Servo Processor Location
1 8 KIBIS Location
1 A FIBIS Location
1 B Centronics Location
1 C NVRAM Location
2 0 EEROM Page Count Low
