8-24 Troubleshooting
Table 8-4. EEROM Map (Continued)
Address
Definition
Location
5
E EEROM Pen 1, Pen 2 First Nozzle
EEROM New Align
6 0 EEROM Platen Factory
6 1 EEROM Platen User
6 2 EEROM Cut Count Low
6 3 EEROM Cut Count High
6 4 EEROM Pen K DT Offset
6 5 EEROM Pen M DT Offset
6 6 EEROM Bail Errors
6 7 Bail Up Pos Offset
6 8 EEROM Page Format Byte
6 9 EEROM Plot Manage Byte
6 A EEROM Block Flag
6 B EEROM Block Checksum
6 C EEROM Block Address
6 D EEROM Block Size
6 E EEROM Block Data
7 E EEROM Block Data End
7 F CHKSUM Byte
EEROM Size
D 4 EEROM Checksum Value
10 1 EEROM Palette Start
14 0 EEROM Palette End
14 1 EEROM PostScript Block 2 Start
EEROM PostScript Start
EEROM PostScript End
17 F EEROM PostScript Block 2 End
96 EEROM PostScript LEN
