8-26 Troubleshooting
The block of text on the configuration plot that shows the contents of the EEROM appears in
the form shown in Table 8-6. This table is a sample portion of the text block from a configura-
tion plot. The contents of the EEROM that you are testing may differ from this sample.
Table 8-6. EEROM Contents Text Block
0 1 2 3 4 5 6 7 8 9 a b c d e f
0: 55 aa 5b 0 4 0 4 f6 60 2c eb f1 e 0 0 4
10: 0 0 0 0 0 1 d0 7 3c 1 63 1 73 7a 4f 0
20: 24 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
30: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
40: 0 0 0 40 25 41 0 61 48 83 8c 0 0 0 1 0
50: 0 0 7 6 7 7 5e 6 3d 0 0 0 0 0 0 0
60: 50 0 0 0 f0 ec 0 c7 0 1 0 c 47 1 e1 0
70: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 8c
80: 55 aa 5b 0 4 0 4 f6 60 2c eb f1 e 0 0 4
90: 0 0 0 0 0 1 d0 7 3c 1 63 1 73 7a 4f 0
a0: 24 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
b0: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
c0: 0 0 0 40 25 41 0 61 48 83 8c 0 0 0 1 0
d0: 0 0 7 6 7 7 5e 6 3d 0 0 0 0 0 0 0
e0: 50 0 0 0 f0 ec 0 c7 0 1 0 c 47 1 e1 0
f0: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 8c
