10-10 Parts and Diagrams
Parts List, C2858A Electronics Enclosure
Ref.
Des.
HP Part
Number
C
D
Qty Description
1 C1633-40059 1 2 GUIDE, MIO SUPPORT
2 0515-0380 2 15 SCREW, MACH M4X10
3 C1633-00033 7 1 SUPPORT, MIO
4 0515-1249 4 20 SCREW, MACH
5 C2858-60105 3 1 PCA, INTERCONNECT
6 C2847-60004 8 1 ENCLOSURE, OUTER (MAIN PCA)
7 C1633-00031 5 1 COVER, MIO
8 0515-2246 3 10 SCREW, TORX/SLOT M3
9 0570-1316 2 2 SCREWLOCK, FEMALE (RS-232)
10 0515-1084 5 2 SCREW, MACH M3X12
11 0515-1349 5 2 SCREW, MACH M3
12 3160-0814 7 1 FAN, TUBEAXIAL
13 0400-0369 4 1 GROMMET, CHANNEL
14 C2847-60018 4 1 ENCLOSURE, INNER (POWER SUPPLY)
15 1400-1642 9 2 CLIP, CABLE-FLAT
16 0515-0390 4 1 SCREW, MACH M4X6
17 C1633-60020 8 1 AC POWER RECEPTACLE ASSEMBLY
18 C1633-00080 4 1 INSULATOR, BOTTOM
19 0950-2417 2 1 PCA, POWER SUPPLY
20 9170-1533 6 2 CLAMP, FERRITE
21 9170-1535 8 2 FERRITE, SPLIT-RECT
22 C2858-60024 5 1 CABLE ASSEMBLY, TRAILING
23 C2847-00019 9 1 INSULATOR, POWER SUPPLY
24 C1633-00105 4 1 LABEL, INSULATOR
25 C2847-00027 9 1 COVER, SIMM
26 C2858-69104 0 1 PCA, MAIN (REBUILT); C2858-60104 CD=2 (NEW)
27 156474 2 1 IC, EPROM (U42)
28 C2858-18012
C2858-18013
C2858-18014
C2858-18015
2
3
4
5
1
1
1
1
IC, PROGRAMMED, EPROM0 (U31)
IC, PROGRAMMED, EPROM1 (U30)
IC, PROGRAMMED, EPROM2 (U33)
IC, PROGRAMMED, EPROM3 (U32)
29 0535-0043 6 2 NUT, HEX M4X0.7
30 C2847-60005 9 1 CABLE ASSEMBLY, MAIN BD PWR
31 C2847-40007 9 1 BARRIER, SIMM
32 C2065A
C2066A
4
5
SIMM 4MB (OPTION: SEE CHAPTER 1)
SIMM 8MB (OPTION: SEE CHAPTER 1)
33 MODULE, ROM (OPTION: SEE CHAPTER 1)
34 C2847-00010 0 1 COVER, ELECTRONICS ENCLOSURE
35 C2858-60011 0 1 CABLE ASSEMBLY (WIRE HARNESS)
