10-12 Parts and Diagrams
Parts List, Left Endcover and Trim
Ref.
Des.
HP Part
Number
C
D
Qty Description
1 C2858-40013 2 1 ENDCOVER ASSEMBLY, LEFT
2 C2858-00018 1 1 LABEL, SERIAL NUMBER
3 1 SIDEPLATE (part of chassis assembly, see page 10-32)
4 C2858-40028 7 1 TRIM, LEFT REAR
5 0515-2254 3 4 SCREW, FLAT M4X16
6 0515-2304 9 1 SCREW/BOLT METRIC
7 0515-2250 9 2 SCREW, FLAT, TAPTITE M4
8 C2858-40026 5 1 TRIM, LEFT FRONT
9 0515-2246 3 6 SCREW, TORX/SLOT M3
10 C2847-60044 1 1 CABLE ASSEMBLY, AC POWER SWITCH
11 0515-0380 2 1 SCREW, MACH M4X10
12 0510-0787 3 1 CLAMP, CABLE .312D
13 1400-0482 3 3 CLAMP, CABLE
14 C1633-40096 6 1 COVER, SWITCH
15 5041-1203 0 1 KEY CAP, POWER SWITCH
16 C2858-00017 9 1 NAME PLATE
