10-14 Parts and Diagrams
Parts List, Right Endcover and Trim
Ref.
Des.
HP Part
Number
C
D
Qty Description
1 0515-2250 9 2 SCREW, FLAT, TAPTITE M4
2 0515-2254 3 4 SCREW, FLAT M4X16
3 C2858-40025 4 1 TRIM, RIGHT FRONT
4 C2858-40027 6 1 TRIM, RIGHT REAR
5 0515-2304 9 1 SCREW/BOLT METRIC
6 1 SIDEPLATE (part of chassis assembly, see page 10-32)
7 3101-3153 9 1 WINDOW SENSOR ASSEMBLY
8 0624-0616 8 2 SCREW, 4-20X0.625 IN LG PLST
9 C1633-40094 4 1 HOLDER, HELP CARD
10 C2847-60061 7 1 HARDWARE KIT
11 C2858-40012 9 1 ENDCOVER, RIGHT
12 0515-2246 3 2 SCREW, TORX/SLOT M3
13 9170-1533 6 2 CLAMP, FERRITE
14 C1633-00093 9 1 BRACKET, TOROID
15 0515-2278 1 4 SCREW, METRIC
16 C2858-60018 7 1 CABLE ASSEMBLY, FRONT PANEL
17 C2858-60057 4 1 FRONT PANEL ASSEMBLY
18 C2858-60026
C2858-60027
C2858-60028
C2858-60029
C2858-60030
C2858-60031
C2858-60033
7
8
9
0
3
4
6
1
1
1
1
1
1
1
OVERLAY, FRONT PANEL (ENGLISH)
(GERMAN)
(SPANISH)
(FRENCH)
(JAPANESE)
(ITALIAN)
(PORTUGUESE)
19 C2858-20007 0 1 EXTENSION, SIDEPLATE
20 0515-2282 7 2 SCREW, MACH
21 0515-2248 5 1 SCREW, MACH
