HP 650C - Page 172

10-16 Parts and Diagrams
Parts List, Rollfeed Components
Ref.
Des.
HP Part
Number
C
D
Qty Description
1 C2847-60013
C1633-60064
9
0
1
1
ROLLCOVER ASSEMBLY MODEL C2858A
MODEL C2859A
2 C2847-80001
C1633-80004
7
0
2
2
SPRING, ROLLCOVER MODEL C2858A
MODEL C2859A
3 0515-2253 2 2 SCREW, TAPTITE W/WASHER M3
4 C1633-20021 5 2 SCREW, SHOULDER
5 0380-3073 9 2 SPACER, SPRING
6 C2847-60033
07596-60060
3
7
1
1
SPINDLE ASSEMBLY MODEL C2858A
MODEL C2859A
7 C2847-60063 9 1 ROLLFEED ASSEMBLY, LEFT
8 0515-2248 9 6 SCREW, THRD, RLLG
9 C2847-60064 0 1 ROLLFEED ASSEMBLY, RIGHT
10 C1633-00084 8 1 LABEL, ROLL LOADING
11 C1633-00131 6 1 LABEL, MEDIA LOADING
12 07596-40077 4 1 SPINDLE SPACER
