10-22 Parts and Diagrams
Parts List, Carriage Axis Drive (Right End)
Ref.
Des.
HP Part
Number
C
D
Qty Description
1 C2858-60023 4 1 PEN CARRIAGE ASSEMBLY (SEE PAGE 10-25)
2 C2847-00029
1500-0856
1
7
1
1
BELT, MAIN DRIVE MODEL C2858A
MODEL C2859A
3 C2858-00028
C2859-00005
3
7
1
1
TRAILING CABLE TRAY, FRONT MODEL C2858A
MODEL C2859A
4 9170-1536 9 1 FERRITE RING
5 C2858-00027 2 1 WASHER, TOROID
6 0515-0380 2 5 SCREW, MACH M4X10
7 07570-60112 0 1 IDLER DRIVE PULLEY
8 07550-40104 4 1 CAM, TENSIONER
9 1460-2061 4 1 SPRING, DRIVE TENSIONER
10 0515-1349 5 1 SCREW, MACH M3
11 07575-40125 8 1 BRACKET, TENSIONER
12 C2858-00007 8 1 BRACKET, ENCODER SPRING
13 C1633-60029 7 1 BRACKET, Y-DRIVE ASSEMBLY
14 C2858-00006 7 1 SPRING, ENCODER
15 C2847-00042
C2848-00011
8
2
1
1
ENCODER STRIP MODEL C2858A
MODEL C2859A
16 3050-0026 0 1 WASHER, 3.2MM
17 0535–0031 2 1 NUT, HEX, M3X0.5
18 C1633-20034 0 2 BEARING, DOUBLE PULLEY
19 1500-0855 6 1 BELT, Y-AXIS DRIVE, SMALL
20 07570-60043 6 1 DOUBLE PULLEY
21 0515-2248 9 4 SCREW, THRD RLLG
22 3140-0907 7 1 MOTOR, CARRIAGE
To Next Page
