HP 650C User Manual

10-24 Parts and Diagrams
Parts List, Pen Carriage Assembly
Ref.
Des.
HP Part
Number
C
D
Qty Description
1 C2858-60023 4 1 PEN CARRIAGE ASSEMBLY
2 C2858-40016 3 2 BUSHING, FRONT
3 C1633-80014 2 1 SPRING, PRELOAD
4 C2858-40017 4 1 BUSHING, REAR
5 0624-0737 4 4 SCREW, 2-28 X .375 PLASTITE
6 C2858-60010 9 1 IC–ENCODER ASSEMBLY
7 C2858-60014 3 1 LINE DETECT ASSEMBLY
8 07575-40013 3 1 LEFT CLAMP, MAIN BELT
9 07575-40014 4 1 RIGHT CLAMP, MAIN BELT
10 C2847-00029
1500-0856
1
4
1
1
BELT, MAIN DRIVE MODEL C2858A
MODEL C2859A
