10-30 Parts and Diagrams
Parts List, Pincharm Assembly
Ref.
Des.
HP Part
Number
C
D
Qty Description
1 0515-1992 4 2 SCREW, M2.5X20
2 C1633-40029 5 2 CAM, JOURNAL
3 0535-0026 5 2 NUT, HEX, DBL-CHAM
4 C2847-20005
C1633–20012
5
4
1
1
CAM, MANUAL PINCHARM LIFT MODEL C2858A
MODEL C2859A
5 C1633-60039 9 4
6
PINCHARM ASSEMBLY MODEL C2858A
MODEL C2859A
6 C1633–80005 2 4
6
SPRING, PINCHARM MODEL C2858A
MODEL C2859A
7 C1633-40082 0 4
6
BUSHING, PINCHARM MODEL C2858A
MODEL C2859A
8 0515-0382 4 1 SCREW, METRIC
9 C1633-00100 9 1 MEDIA EDGE DIRECTOR
10 C1633-00076 8 1 WIRE LINK, REAR
11 C1633-40079 5 1 PLATE, ROCKER
12 C1633-80007 3 1 SPRING, ROCKER
13 C1633-20021 5 1 SCREW, SHOULDER
14 0624-0647 5 2 SCREW, TAPPING, 4-20
15 C2847–60022 0 1 SENSOR, PINCHARM
16 C1633-00075 7 1 WIRE LINK, FRONT
17 0624-0704 5 1 SCREW, 6-19X0.375 PLST
18 2190-0760 4 1 WASHER, 5.1MM
19 C1633-40078 7 1 CAM, DRIVE LEVER
20 0515-2278 4 6 SCREW, MACH
21 1400-1021 8 2 CLAMP, CABLE
22 C1633-00024 6 2 PAN
23 C1633-40030 8 1 LEVER, MANUAL LIFT
24 C1633-00059 7 1
2
MEDIA DIVERTER MODEL C2858A
MODEL C2859A
