HP 650C - Page 188

10-32 Parts and Diagrams
Parts List, Starwheel, Starguard and Chassis Assemblies
Ref.
Des.
HP Part
Number
C
D
Qty Description
1 0515-2337 3 2 SCREW, LONG, DOGPOINT
2 0515-2304 9 2 SCREW/BOLT METRIC
3 0515-2333 9 4 SCREW, THRD RLLG
4 C2847-60009
C1633-60032
3
2
1
1
STARGUARD ASSEMBLY MODEL C2858A
MODEL C2859A
5 C1633-60051 5 6
9
STARWHEEL ASSEMBLY MODEL C2858A
MODEL C2859A
6 C2858-00014
C2859-00004
7
6
1
1
PANEL, WINDOW MODEL C2858A
MODEL C2859A
7 C2858-60021 2 1 CUTTER ASSEMBLY
8 C1633-40067 1 1 BUSHING, CUTTER
9 1 SLIDER ROD, REAR (PART OF ITEM 11)
10 1 SLIDER ROD, FRONT (PART OF ITEM 11)
11 C2858-60025
C2859-60003
6
1
1
1
CHASSIS ASSEMBLY MODEL C2858A
MODEL C2859A
12 C2847-60011
C1633-60047
7
5
1
1
CUTTER ENCLOSURE AY MODEL C2858A
MODEL C2859A
13 C1633-40077 3 3
4
GUIDE, MEDIA MODEL C2858A
MODEL C2859A
