3-25Installation and Configuration
Message Action
Pull / Align
edges to roll
Grasp the left and right free edges of the roll media and pull toward
you until the media is taut. At the same time, align the left and right
edges of the media so that they are flush with the left and right edges of
the roll.
Remove media
Continue
Ink is dry; you can remove the accuracy calibration plot the plotter just
produced. Press Down Arrow to continue with accuracy calibration.
Replace
Y, C, M, K pen
Y, C, M, or K pen has a clogged nozzle. You must replace the defective
pen to continue. Defective pen position is indicated by a flashing icon
in the display.
Reseat
Y, C, M, K pen
Y, C, M, or K pen has not made proper contact in the pen slot. Remove
the appropriate pen and reseat it in the slot. Defective pen position is
indicated by a flashing icon in the display.
Sheet load
Roll load
Press Up Arrow to load sheet media.
Press Down Arrow to load roll media.
Sheet / Roll?
Reload media
You have chosen Sheet mode while loading roll media. Reload media.
You have loaded a sheet more than 51 inches (130 cm) long. Trim
sheet and reload.
