HP 650C - Page 68

6-10 Removal and Replacement
Figure 6-5.
RS-232-C Parallel
Fan
Power Dist.
Interconnect PCA
Trailing
Cable
X-axis Encoder
Media Sensor
Pinch Wheel Sensor
Front
Panel
Drop
Sensor
Nuts
(2)
Screws
(12)
Main PCA Cable Connectors
(C)C2858-44
EPROMs
(L)C2858-3
