6-33Removal and Replacement
Figure 6-23.
Cutter AssemblyStarguard
Right Pre-load Arm
Cutter Blade
Linear Cutter Blade
Overdrive Support
Assembly
Bottom Finger of
Cutter Assembly
Slider Rod
Bushing
Cutter Blade
Linear Blade
Starguard
Upper Wheels
Lower Wheels
Overdrive Support Assembly
Side View
Front View
(C)C2858-55
(C)C2858-66
