6-39Removal and Replacement
Figure 6-26.
Encoder Strip Bracket
Encoder Strip
Nut & Washer
Encoder Strip Spring
Carriage PCA
Trailing Cable
Connector
Trailing Cable
Bracket
(C)C2858-47a
Encoder Strip
Small Drive Belt
Y-Drive Bracket
Cutter Assembly
(C)C2858-77
